| Supply Voltage | VBAT: 3.5 V ~ 4.2 V, typical: 3.8 V |
| Dimensions | 43 mm x 44 mm x 2.85 mm |
| Package | 152 – pin LCC + 171 - pin LGA |
| MCP | 128 GB UFS + 6GB LPDDR4X 64 GB eMMC + 4GB LPDDR4X |
| Frequency Bands | CN: LTE FDD: B1/B3/B5/B8 LTE TDD: B34/B38/B39/B40/B41 WCDMA: B1/B5/B8 GSM: 900/1800MHz EU: LTE FDD: B1/B3/B5/B7/B8/B20/B28 LTE TDD: B38/B40/B41 WCDMA: B1/B5/B8 GSM: 850/900/1800MHz |
| Camera | 3*MIPI_CSI interface, supporting up to 48MP resolution and a maximum of triple-camera simultaneously |
| Certifications | CCC*/SRRC*/CE*/RoHS* |
| Regions | Chinese Mainland / India / Southeast Asia / Europe / Africa |
